Pipe and duct components
Individually planned, optimally designed
Drawing on our expertise in air technology plants in the most varied of application areas, we offer a comprehensive range of welded pipe and duct components. We offer customized design and planning for the most varied of customer requirements, providing an economical and efficient solution.
Our standardized product range includes welded pipes and ducts and the associated moulded parts such as bends, branches, T-pieces, reducers, adapters, channels, deflectors, extraction hoods, etc. They are connected using welded or rotating flanges (DIN 24154 series 4) and welded frames (DIN 24158 series 4).
We also offer an intelligent support and suspension concept that adapts to the structural situation to ensure straightforward assembly and fastening. Our outstanding in-house production, vertical range of manufacture and assembly and a carefully selected network of partners ensure exceptional product quality.
The following designs and dimensions are available:
- NW 80 to NW 5000//NW 100 x 100 to 5,000 x 5,000
- Lengths up to 6 m
- Wall thicknesses from 2 to 6 mm
- Pressure levels up to +/- 15,000 Pa
- Sheet steel; rust, acid, or heat-resistant stainless steels; wear-resistant steels
